Filigree design for healthy living

The Soundline M box window from Solarlux is an innovative solution for increased sound insulation in urban living situations. It was specifically developed to meet the requirements of healthy living and designed for use on windows in new builds and renovations. The Soundline M system was designed and tested by SG-Bauakustik in collaboration with the engineering firm IfB Sorge, a specialist in building physics. With the attached module, increased sound insulation of up to 20 dB compared to the simple standard window can be achieved. In addition, the box window impresses with its raised thermal insulation and elegant , delicate appearance.
Solarlux holds a patent for the Soundline M: Patent pending No. 10 2025 132 544.

Kastenfenster für Schallschutz und Gewerbelärm
Kastenfenster für Schallschutz und Gewerbelärm

Performance: sound insulation and thermal insulation

The advanced Soundline M modules ensure increased sound insulation as well as additional thermal insulation.

sound insulation: tested by SG-Bauakustik:
Rating according to ISO 717-1: Rw (C;Ctr) = 50 (-1;-5) dB

  • Sound insulation closed: up to 50 dB
  • Sound insulation ventilation position: up to 37 dB

Thermal insulation: thermal testing by building - Ingenieurbüro für Bauphysik

  • Standard window Alu
    Uw, box window = 1.1 (1.086) W/m²K
  • Standard window wood
    Uw, box window = 0.69 (0.691) W/m²K



Kastenfenster für urbanen Wohnungsbau
Kastenfenster für urbanen Wohnungsbau

Advantages at a glance

  • Certified modular system for upstream installation
  • Tested performance values for sound insulation and thermal insulation
  • Natural ventilation to prevent overheating
  • Easy cleaning of the outer panes from the inside
  • Plug and play installation for quick installation
  • Floor-to-ceiling elements with integrated fall protection possible
  • Optionally with integrated shading elements
  • Filigree glass look without vertical profiles
  • Maximum light transparency
  • Patented solution: Patent pending No. 10 2025 132 544.8
„The Soundline M product group is a certified and innovative box window. Due to the individual adaptation options in the system design, all requirements in the areas of sound insulation, climate loads and safety are solved. The patented system ensures natural and concealed interior ventilation. Simply ingenious and a "must have" when it comes to sound insulation in the external facade! Interfaces to window systems and building connections were optimally designed and tested. The delicate and cubic exterior design is exactly the architectural approach in today's world. “
Michael Meyer
Teamlead Productmanagement Solarlux

Engineering & Downloads

Systemschnitt Proline A
Systemschnitt Proline A

Technical details

building depth: 180mm/500mm
sound insulation closed: Up to 50 dB
sound insulation Ventilation position: Up to 37 dB
Frame material: aluminium with integrated absorbers
Interior element: wood, aluminium or plastic
Exterior element: Proline T or sliding system Proline S
Cleaning: Possible from the inside
Installation: Plug & Play
